Dyson Airblade Wash and Dry Short WD04
Product code:
1851446
View Product Specifications
Product Specifications
Warranty Information
Documents and Downloads
Back
Features
-Touch-Free Infra-Red Activation -14 Second Hand Dry Time -30 Second Operation Lockout Period -Equipped with Automatic Duty Flush (every 24 hours for 60 seconds after the last use)
Recommended Use
Commercial, Domestic & Hotel
Commercial Sector
Education, Public Spaces & Ambulant (AS 1428.1)
Product Type
Outlet
Application Place
Basin
Mounting
Wall
Model Number
247896-01
Primary Material
Stainless Steel
Width
303 mm
Depth
286 mm
Height
159 mm
Weight
4.26 kg
IP Rating
IP35
Phase
Single Phase
Nominal Power Supply
230V AC
Maximum Inlet Pressure
800 kPa
Spare Parts & Labour
5 Years
Learn about our
Product Quality Guarantee
Care & Maintenance - Dyson Airblade Wash and Dry
View
Installation Instructions - Dyson Airblade Wash and Dry Tall WD05 & Short WD04
View
Specification, Manuals & Installation
Care & Maintenance - Dyson Airblade Wash and Dry
View
Installation Instructions - Dyson Airblade Wash and Dry Tall WD05 & Short WD04
View
Accessibility Guidelines - Dyson Airblade Wash and Dry Wall WD06 & Short WD04
View
Specification Sheet - Dyson Airblade Wash and Dry
View
